YFJ-D800 12''-32'' Butterfly Valve Test Bench

  • YFJ-D800 Butterfly Valves Test Bench
YFJ-D800 Butterfly Valves Test Bench

YFJ-D800 Butterfly Valves Test Bench

  • Valve Types: Butterfly Valve/Knife Gate/Wafer Check
  • Size Range: 12''-32'' DN300-DN800
  • Pressure Range: Class 150-Class300
  • Valve End Type: Flanged/Wafer
  • Product description: Equiped with Low Pressure Pump/High Pressure Pump Hydraulic Systsem,Electrical Control System
  • INQUIRY

YFJ-D800 Butterfly Valve Testing Bench

(12’’-32’’ DN300-DN800)




Key Features:

Designed to test Butterfly Valve/Wafer CheckValve/Knife Gate Valves

Size range: 12’’-32’’ DN50-DN800

Pressure range: Class 150-Class300 PN16-PN40

( Pressure to be confirmed as different customers require different pressure ,

customization services available )

Hydraulic Clamping system with  jaws, by means of clamping flanges

with blind flange adaptors ensure the positive seals of the valve flanges.

Vertical Design

Stainless steel tubes and pipelines available

With interlock functions for safety

Testing fluid by water or air ,water with a corrosion inhibitor,

according to international valve testing& Inspection standard like API598 etc

Recycle water tanks

Air driven liquid booster pump(Maximator or Haskel)

Data acquisition system is available, including PLC,Touch screen,

Printer,with test graphs & reports.


We can customize the machine for you, please send all your details to info@dorytestbench.com
